all manual transmission Note: Requires use of VIG7074TCS to complete wiring to T.C.S. switch located in passenger side cylinder head
CONNECTS TO:
- Dash Harness Connection (at firewall)
- Ground (to bell housing bolt)
- Ground (to passenger side T.C.S. relay mounting bolt)
- Heater Blower Motor (cars without A/C)
- Heater Blower Motor Ground Terminal (cars without A/C)
- Horn Relay
- Ignition Coil ("+" terminal)
- Starter Solenoid
- T.C.S. Delay Relay (located on firewall)
- T.C.S. Reversing Relay (located on firewall)
- T.C.S. Solenoid / Idle Stop Solenoid (on intake manifold)
- T.C.S. Switch Harness Connection (in passenger side cylinder head)
- T.C.S. Switch (on transmission)
- Windshield Washer Pump
- Windshield Wiper Door Limit Switch Connection
- Windshield Wiper Motor
- Windshield Wiper Motor Ground Terminal
- Windshield Wiper Motor Connection
Vehicle Fitment:
The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
| Make |
Model |
Years |
| Chevrolet |
Corvette |
1971 |
IMPORTANT: Electrical items are covered by a 30 day EXCHANGE ONLY WARRANTY. There are no returns or refunds on such items.
